Metallized Polyester Film Capacitor Mini Size | CD
CDAF Series are constructed with metalized polyester film dielectric, Kupferblei und Epoxidharz-Pulverbeschichtung. Sie eignen sich zum Blockieren, Kupplung, Entkopplung, Filterung, Bypass-Zeitschaltung und ideal für den Einsatz in Telekommunikationsgeräten, Datenverarbeitungsgeräte, Industrieinstrument, automatic control systems and other general electronic equipment.
MERKMALE
◆ Betriebstemperatur. Reichweite :-40°C ~ +125°C (Derates over 105°C)
◆ Kapazitätsbereich:0.001~1.2uF
◆ Kapazitätstoleranz: J=5 % K=10 % M=20 %
◆ Nennspannung V R 85°C: 50V, 63V,100Vdc, 250Vdc, 400Vdc, 450Vdc, 630Vdc,1000Vdc
BEISPIEL FÜR TEILENUMMERN
TOLERANCE
| Code | Toleranz |
| J | ±5 % |
| K | ±10 % |
| M | ±20 % |
LEAD STYLE EXAMPLES
KAPAZITÄTSCODE
| F | 0.01 | 0.047 | 0.1 | 0.47 | 1.0 |
| pF | 10000 | 47000 | 100000 | 470000 | – |
| Code | 103 | 473 | 104 | 474 | 105 |
Nennspannung
| WV | 50 | 63 | 100 | 250 | 400 | 630 |
| Code | 1H | 1J | 2A | 2E | 2G | 2J |
PACKAGING
| Meth | od | Schüttgut | Munition | Spule |
| Code | B | A | R | |
LEITUNGSLÄNGE VON DER SITZEBENE
(Bulk Pack)
| mm | 5 | 10 | 15 | 20 | 25 |
| Code | 050 | 100 | 150 | 200 | 250 |
TAPE CODE (Lead spacing of tape)
| Raum | G | 5mm |
| Verpackung | A oder R | |
| Code | RT1 (See Diagram) | |
LEAD-STIL
| Code | Stil |
| S | Gerade |
| K | Kink-In (Abstand halten) |
| F | Form aus |
| ICH | Formular ein |
** For Bulk packaging with formed leads, add an additional 3 digit lead spacing code at end of part number.
MAXIMALE ABMESSUNGEN (mm)
| W. V. | 50 / 63VDC (1H/1J) | 100VDC(2A) | 250VDC(2E) | 400VDC(2G) | 630VDC (2J) | ||||||||||||||||||||
| ( μF) | Code | W | H | T | P | D | W | H | T | P | D | W | H | T | P | D | W | H | T | P | D | W | H | P | D |
| 0.001 | 102 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | 6.5 | 6.5 | 5 | 0.5 |
| 0.0022 | 122 | 6.5 | 6.5 3.5 5 | 0.5 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | 6.5 | 6.5 | 5 | 0.5 | ||
| 0.0033 | 332 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | 6.5 | 6.5 | 5 | 0.5 |
| 0.0047 | 472 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | 6.5 | 6.5 | 5 | 0.5 |
| 0.0056 | 562 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | ||||
| 0.0068 | 682 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | ||||
| 0.0082 | 822 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | ||||
| 0.010 | 103 | 6.5 | 6.5 | 4.0 | 5 | 0.5 | 6.5 | 6.5 | 4.0 | 5 | 0.5 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | ||||
| 0.012 | 123 | 6.5 | 6.5 | 4.0 | 5 | 0.5 | 6.5 | 6.5 | 4.0 | 5 | 0.5 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | |||||||||
| 0.015 | 153 | 6.5 | 6.5 | 4.0 | 5 | 0.5 | 6.5 | 6.5 | 4.0 | 5 | 0.5 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | |||||||||
| 0.018 | 183 | 6.5 | 6.5 | 4.0 | 5 | 0.5 | 6.5 | 6.5 | 4.0 | 5 | 0.5 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | |||||||||
| 0.022 | 223 | 6.5 | 6.5 | 4.0 | 5 | 0.5 | 6.5 | 6.5 | 4.0 | 5 | 0.5 | 6.5 | 6.5 | 3.5 | 5 | 0.5 | |||||||||
| 0.027 | 273 | 6.5 | 6.5 | 4.0 | 5 | 0.5 | 6.5 | 6.5 | 4.0 | 5 | 0.5 | 7.5 | 9.5 | 3.5 | 5 | 0.5 | |||||||||
| 0.033 | 333 | 6.5 | 6.5 | 4.0 | 5 | 0.5 | 6.5 | 6.5 | 4.0 | 5 | 0.5 | 7.5 | 9.5 | 4.5 | 5 | 0.5 | |||||||||
| 0.039 | 393 | 6.5 | 6.5 | 4.0 | 5 | 0.5 | 6.5 | 6.5 | 4.0 | 5 | 0.5 | 7.5 | 9.5 | 4.5 | 5 | 0.5 | |||||||||
| 0.047 | 473 | 6.5 | 6.5 | 4.0 | 5 | 0.5 | 6.5 | 6.5 | 4.0 | 5 | 0.5 | 7.5 | 9.5 | 4.5 | 5 | 0.5 | |||||||||
| 0.056 | 563 | 6.5 | 6.5 | 4.0 | 5 | 0.5 | 6.5 | 6.5 | 4.0 | 5 | 0.5 | 7.5 | 9.5 | 4.5 | 5 | 0.5 | |||||||||
| 0.068 | 683 | 6.5 | 6.5 | 4.0 | 5 | 0.5 | 6.5 | 6.5 | 4.0 | 5 | 0.5 | 7.5 | 9.5 | 4.5 | 5 | 0.5 | |||||||||
| 0.082 | 823 | 6.5 | 6.5 | 4.0 | 5 | 0.5 | 6.5 | 6.5 | 4.0 | 5 | 0.5 | 7.5 | 9.5 | 4.5 | 5 | 0.5 | |||||||||
| 0.1 | 104 | 6.5 | 6.5 | 4.5 | 5 | 0.5 | 6.5 | 6.5 | 4.5 | 5 | 0.5 | 7.5 | 9.5 | 4.5 | 5 | 0.5 | |||||||||
| 0.12 | 124 | 6.5 | 6.5 | 4.5 | 5 | 0.5 | 6.5 | 6.5 | 4.5 | 5 | 0.5 | 7.5 | 10 | 5.0 | 5 | 0.5 | |||||||||
| 0.15 | 154 | 6.5 | 6.5 | 4.5 | 5 | 0.5 | 6.5 | 6.5 | 4.5 | 5 | 0.5 | 7.5 | 10 | 5.0 | 5 | 0.5 | |||||||||
| 0.18 | 184 | 6.5 | 6.5 | 4.5 | 5 | 0.5 | 6.5 | 6.5 | 4.5 | 5 | 0.5 | 7.5 | 10 | 6.0 | 5 | 0.5 | |||||||||
| 0.22 | 224 | 6.5 | 6.5 | 4.5 | 5 | 0.5 | 6.5 | 6.5 | 4.5 | 5 | 0.5 | 7.5 | 10 | 6.0 | 5 | 0.5 | |||||||||
| 0.27 | 274 | 6.5 | 6.5 | 4.5 | 5 | 0.5 | 6.5 | 6.5 | 4.5 | 5 | 0.5 | 7.5 | 10.5 | 7.0 | 5 | 0.5 | |||||||||
| 0.33 | 334 | 6.5 | 6.5 | 4.5 | 5 | 0.5 | 6.5 | 6.5 | 4.5 | 5 | 0.5 | 7.5 | 11 | 7.0 | 5 | 0.5 | |||||||||
| 0.39 | 394 | 6.5 | 6.5 | 4.5 | 5 | 0.5 | 6.5 | 6.5 | 4.5 | 5 | 0.5 | 7.5 | 12 | 8.0 | 5 | 0.5 | |||||||||
| 0.47 | 474 | 7.0 | 7.5 | 4.5 | 5 | 0.6 | 7.0 | 7.5 | 4.5 | 5 | 0.6 | 7.5 | 12 | 8.5 | 5 | 0.5 | |||||||||
| 0.56 | 564 | 7.0 | 8.5 | 5.0 | 5 | 0.6 | 7.0 | 8.5 | 5.0 | 5 | 0.6 | ||||||||||||||
| 0.68 | 684 | 7.0 | 8.5 | 5.0 | 5 | 0.6 | 7.0 | 8.5 | 5.0 | 5 | 0.6 | ||||||||||||||
| 1.0 | 824 | 7.0 | 8.5 | 5.0 | 5 | 0.6 | 7.0 | 10 | 6.0 | 5 | 0.6 | ||||||||||||||
| 1.5 | 155 | 7.0 | 10.0 | 6.5 | 5 | 0.5 | 7.0 | 10 | 6.0 | 5 | 0.6 | 17 | 15 | 7.0 | 15 | 0.8 | |||||||||
| 2.2 | 225 | 7.0 | 10.0 | 6.5 | 5 | 0.6 | 7.0 | 10.5 | 7.0 | 5 | 0.6 | 17 | 15.5 | 6.5 | 15 | 0.8 | |||||||||
LEISTUNG
| Artikel | Metallisiert Polyester |
| Kapazitätsdrift | Durchlief den Betriebstemperaturbereich 2%. |
| Feuchtigkeitstest | Will withstand the test of R.H. 95% at 40°C for 1000hrs. C < 5% DF < 1.2% UND > 10000MΩ |
| Belastungstest | Will withstand a testing voltage at 140% von W.V. for 1000hrs at 85°C. C < 5% DF < 1.2% UND > 5000MΩ |
| Bleizugtest | Will withstand a pull of 1.5Kg applied axialy for 10 Sekunden. |
|
Bleibiegetest |
Will sustain two cycles without breaking when attaching a load of 0.5Kg to the end of the lead and then rotating the capacitor 90º from the direction of lead egress. Then 180 in opposite direction, then back to the starting point. |
| Lötbarkeit | Eingetaucht in geschmolzenes Lot (230 + 0.5 sec.) after testing, Die Wundleitung und der Spalt in der Wundleitung werden mit Lot abgedeckt und ausgefüllt. Will be difficult to unwind byfinger. |
| Dielectric Strength | Wird standhalten 200% oder 160% of rated voltage at 25°C for 1 minute with current limiting resistance of 1 Oh
/ V. |
LÖTEN
Die Fläche unter der Kurve gibt die empfohlene Lötzeit an & Temp. für die gezeigten Materialien
RADIAL TAPING
SPEZIFIKATIONEN
| Beschreibung |
Letter |
Dimension (mm) |
| RT1 | ||
| Lead Wire Diameter | D | 0.5 / 0.6 |
| Tapping Pitch | P | 12.7 |
| Feed Hole Pitch | PO | 12.7 |
| Centering of the Lead Wire | P1 | 3.85 |
| Centering of the Body | P2 | 6.35 |
| Bleiabstand (Pitch) | F | 5 |
| Component Alignment | ∆h | 0 |
| Height of Componenet from Tape Center | H | 18.5 |
| Carrier Tape Width | W | 18 |
| Hold Down Tape Width | WO | 6 |
| Hole Position | W1 | 9 |
| Hold Down Tape Position | W2 | 3 |
| Feed Hole Diameter | Do | 4 |
| Tape Thickness | T | 0.7 |
| Figure | fig | 1 oder 2 |
Remark: *Allowance of accumulated pitch less than 1mm at the sum of 20 pitches.
*Continuous empty component less than 3 consecutive pieces.
*Total empty on one reel less than 1%.
EINFÜHRUNG
CDAF Series are constructed with metalized polyester film dielectric, Kupferblei und Epoxidharz-Pulverbeschichtung. Sie eignen sich zum Blockieren, Kupplung, Entkopplung, Filterung, Bypass-Zeitschaltung und ideal für den Einsatz in Telekommunikationsgeräten, Datenverarbeitungsgeräte, Industrieinstrument, automatic control systems and other general electronic equipment.
