Há hitastig tantal þéttar 185 ℃|CBGY
CHARACTERS AND USES
●SilVer case, gas innsigli, Sívalur, Ásleiðir, Háhita sleeVe, Polar
●Good electric performance, Mikill áreiðanleiki, langt líf, Lágt DF og LC.
●Hátt hitastig árangur, Getur notað kl 185 ℃
●Suit for oil drilling deep well measurements and high temperatureelectronic deVices DC or pulse circuit
●1mplementation of standards: QJ/PWV222-2008
●Equative CA502 series
TechnicaI Performance
●Operation temperature: -55℃~+185℃ (>155℃ use derated Voltage)
●Capacitance Tolerance:± 10%;± 20%;-10%~+30%
●Dissipation Factor: 25℃,100Hz (see table 2)
●Leakage Current:25℃ 1O≤0.002 CRUR(uA)or 2uA (whicheVer is greater)
185℃ 1O≤0.04 CRUR(uA)or 40uA (whicheVer is greater)
Eiginleiki
