Há hitastig tantal þéttar 175 ℃|CBGT
CHARACTERs AND USE
●SilVer case, gas innsigli, Sívalur, Ásleiðir, Háhita sleeVe, Polar
●Good electric performance, Mikill áreiðanleiki, langt líf, Lágt DF og LC.
●Hátt hitastig árangur, Getur notað kl 175 ℃
●Suit for oil drilling deep well measurements and high temperatureelectronic deVices DC or pulse circuit
●1mplementation of standards: QJ/PWV223-2008
●Equative CA501 series
TechnicaI Performance
●Operation temperature:-55℃~+175℃ （>155℃ use derated Voltage)
●Capacitance Tolerance:± 10%;± 20%;-10%~+30%
●Dissipation Factor:25℃,100Hz （see table 1)
●Leakage Current:25℃ 1O≤0.002CRUR(uA）or 2uA （whicheVer is greater)
175℃ 1O≤0.03 CRUR(uA）or 30uA （whicheVer is greater)
Eiginleiki
