Жогорку температура тантал от конденсаторлору 175 ℃|CBGT
CHARACTERs AND USE
●SilVer case, газ пломба, Цилиндрлик, Окторду алып барат, High temperature sleeVe, Polar
●Good electric performance, Жогорку ишенимдүүлүк, узак жашоо, Төмөн DF жана LC.
●High temperature performance, Колдоно алат 175 ℃
●Suit for oil drilling deep well measurements and high temperatureelectronic deVices DC or pulse circuit
●1mplementation of standards: QJ/PWV223-2008
●Equative CA501 series
TechnicaI Performance
●Operation temperature:-55℃~+175℃ （>155℃ use derated Voltage)
●Capacitance Tolerance:± 10%;± 20%;-10%~+30%
●Dissipation Factor:25℃,100Hz （see table 1)
●Leakage Current:25℃ 1O≤0.002CRUR(uA）or 2uA （whicheVer is greater)
175℃ 1O≤0.03 CRUR(uA）or 30uA （whicheVer is greater)
